Pioneer A-8800X

Effective output (15 Hz to 20 kHz) 75W + 75W (8 Ω, both channel drive) Harmonic distortion factor (8 Ω) 0.03% (at effective output) 0.01% (at 37.5W output) 0.01% (at 1W output) Cross modulation distortion factor (50 Hz : 7 kHz = 4 : 1, 8 Ω) 0.03% (at effective output) 0.01% (at 37.5W output) 0.01% (at 1W output) Output bandwidth 5 Hz ~ 50 kHz (Both channel drive, THD 0.03%) Output terminal Speaker, Headset, Tape rec1, 2 (150 mv) Damping factor 40 (15 Hz ~ 20 kHz, 8 Ω) Input Sensitivity / Impedance Phono MM : 2.5mV/25k Ω, 50k Ω, 100k Ω Load Capacity 100 pf, 200 pf, 300 pf Phono MC : 250 μ V/100 Ω Tuner, Aux, Tape play1, 2 : 150mV/50k Ω Phono maximum allowable input (1 kHz, 0.02% THD) MM:200mV MC:20mV Frequency characteristic Phono MM : 20 Hz to 20 kHz ± 0.2 dB Tuner, Aux, Tape play1, 2 : 10 Hz to 100 kHz + 0 -2dB Signal-to-noise ratio (IHF, A-network Short circuit) Phono MM:89dB Phono MC:72dB Tuner, Aux, Tape play : 110 dB تمام فابریک دست نخورده ارسال به سراسر کشور
